CSI 250L Lab 9, Spring 2012

American University of Science & Technology Department Of Computer Science CSI 250L – Computer Programming-II Lab Spring 2011/2012 Lab Work 9 Problem1: Write the definition and implementation of the following classes specifications. Each class definition and implementation should be written in a separate file. II- Write a program to do the following steps in order:  Create a pointer, sptr, to point to an object of class Square that contain the following values: side = 10, color = “Blue”, draw_style = “dotted”.  Output the values stored in sptr. 1 GraphicalObject Attributes  color: a string of characters.  draw_style: a string of characters. Methods  constructor (No default values)  destructor.  Set,get  print Remarks  The color and draw_style attributes should store any number of characters.  The class attributes should be accessible in a derived class implementation. Square Note that a square is a GraphicalObject. Attributes  side: an integer to specify the side length.  Count: for all instantiated objects Methods  constructor (no default values).  destructor.  Compute area : returns the area of a square using the formula area = side*side;  Set, get  print : to output all information about a square as follows: color = orange drawstyle = plain side = 10 area = 100  Write the necessary statements to end the program. Problem 2 : Write the implementation of the following classes as specified below: Address Attributes  city: a String.  area: a String. Methods  Constructors (the default constructor will initialize the Address to spaces.  Print() Teacher Note that a teacher is an employee. 2 Employee Attributes  ID: an integer to identify each employee.  fname: a String .  lname: a String.  address: to store the information about an employee address.  rank: an integer to classify an employee position that can be assigned only the values 1,2, or 3. Methods  constructor (no default constructor).  print: to print information about an employee in the following format: 4567 Imad Faraj lives in Beirut – Hamra, and has rank 2  get_rank: returns the rank of an employee . Attributes  hours: an integer to store the number of hours taught by a teacher.  totalsalary: an integer that is shared by all objects of the class Teacher. It should accumulate the value of all teachers’ salaries. Methods  constructor.  Calculate_salary : return the salary of a teacher. Note that the salary is equal to: -hours * 75000 if rank =1. -hours * 50000 if rank =2. -hours * 40000 if rank =3.  get_totalsalary: returns the value of totalsalary.  print: to print information about a teacher as follows: 4239 Marwan Eid lives in Beirut – Zarif and has rank 2 Hours = 30, Salary = 1500000. II- Write a driver program to instantiate N objects of the class Teacher. You should output the information about the teacher with the highest salary. 3
