CSC 320 Chapter 3, Fall 2012

Chapter 3 Arithmetic for Computers Chapter 3 — Arithmetic for Computers — 2 Arithmetic for Computers � Operations on integers � Addition and subtraction � Multiplication and division � Dealing with overflow � Floating-point real numbers � Representation and operations §3.1 Introduction Chapter 3 — Arithmetic for Computers — 3 Integer Addition � Example: 7 + 6 §3.2 Addition and Subtraction � Overflow if result out of range � Adding +ve and –ve operands, no overflow � Adding two +ve operands � Overflow if result sign is 1 � Adding two –ve operands � Overflow if result sign is 0 Chapter 3 — Arithmetic for Computers — 4 Integer Subtraction � Add negation of second operand � Example: 7 – 6 = 7 + (–6) +7: 0000 0000 … 0000 0111 –6: 1111 1111 … 1111 1010 +1: 0000 0000 … 0000 0001 � Overflow if result out of range � Subtracting two +ve or two –ve operands, no overflow � Subtracting +ve from –ve operand � Overflow if result sign is 0 � Subtracting –ve from +ve operand � Overflow if result sign is 1 Chapter 3 — Arithmetic for Computers — 5 Dealing with Overflow � Some languages (e.g., C) ignore overflow � Use MIPS addu, addui, subu instructions � Other languages (e.g., Ada, Fortran) require raising an exception � Use MIPS add, addi, sub instructions � On overflow, invoke exception handler � Save PC in exception program counter (EPC) register � Jump to predefined handler address � mfc0 (move from coprocessor reg) instruction can retrieve EPC value, to return after corrective action Chapter 3 — Arithmetic for Computers — 7 Multiplication � Start with long-multiplication approach 1000 × 1001 1000 0000 0000 1000 1001000 Length of product is the sum of operand lengths multiplicand multiplier product §3.3 Multiplication Chapter 3 — Arithmetic for Computers — 8 Multiplication Hardware Initially 0 Chapter 3 — Arithmetic for Computers — 11 MIPS Multiplication � Two 32-bit registers for product � HI: most-significant 32 bits � LO: least-significant 32-bits � Instructions � mult rs, rt / multu rs, rt � 64-bit product in HI/LO � mfhi rd / mflo rd � Move from HI/LO to rd � Can test HI value to see if product overflows 32 bits � mul rd, rs, rt � Least-significant 32 bits of product –> rd Chapter 3 — Arithmetic for Computers — 16 MIPS Division � Use HI/LO registers for result � HI: 32-bit remainder � LO: 32-bit quotient � Instructions � div rs, rt / divu rs, rt � No overflow or divide-by-0 checking � Software must perform checks if required � Use mfhi, mflo to access result Chapter 3 — Arithmetic for Computers — 17 Floating Point � Representation for non-integral numbers � Including very small and very large numbers � Like scientific notation � –2.34 × 1056 � +0.002 × 10–4 � +987.02 × 109 � In binary � ±1.xxxxxxx2 × 2yyyy � Types float and double in C normalized not normalized §3.5 Floating Point Chapter 3 — Arithmetic for Computers — 18 Floating Point Standard � Defined by IEEE Std 754-1985 � Developed in response to divergence of representations � Portability issues for scientific code � Now almost universally adopted � Two representations � Single precision (32-bit) � Double precision (64-bit) Chapter 3 — Arithmetic for Computers — 19 IEEE Floating-Point Format � S: sign bit (0 ⇒ non-negative, 1 ⇒ negative) � Normalize significand: 1.0 ≤ |significand| < 2.0 � Always has a leading pre-binary-point 1 bit, so no need to represent it explicitly (hidden bit) � Significand is Fraction with the “1.” restored � Exponent: excess representation: actual exponent + Bias � Ensures exponent is unsigned � Single: Bias = 127; Double: Bias = 1203 S Exponent Fraction single: 8 bits double: 11 bits single: 23 bits double: 52 bits (Exponent Bias) S (1 Fraction) 2 ( 1) x − × + × = − Chapter 3 — Arithmetic for Computers — 20 Single-Precision Range � Exponents 00000000 and 11111111 reserved � Smallest value � Exponent: 00000001 ⇒ actual exponent = 1 – 127 = –126 � Fraction: 000…00 ⇒ significand = 1.0 � ±1.0 × 2–126 ≈ ±1.2 × 10–38 � Largest value � exponent: 11111110 ⇒ actual exponent = 254 – 127 = +127 � Fraction: 111…11 ⇒ significand ≈ 2.0 � ±2.0 × 2+127 ≈ ±3.4 × 10+38 Chapter 3 — Arithmetic for Computers — 21 Double-Precision Range � Exponents 0000…00 and 1111…11 reserved � Smallest value � Exponent: 00000000001 ⇒ actual exponent = 1 – 1023 = –1022 � Fraction: 000…00 ⇒ significand = 1.0 � ±1.0 × 2–1022 ≈ ±2.2 × 10–308 � Largest value � Exponent: 11111111110 ⇒ actual exponent = 2046 – 1023 = +1023 � Fraction: 111…11 ⇒ significand ≈ 2.0 � ±2.0 × 2+1023 ≈ ±1.8 × 10+308 Chapter 3 — Arithmetic for Computers — 22 Floating-Point Precision � Relative precision � all fraction bits are significant � Single: approx 2–23 � Equivalent to 23 × log102 ≈ 23 × 0.3 ≈ 6 decimal digits of precision � Double: approx 2–52 � Equivalent to 52 × log102 ≈ 52 × 0.3 ≈ 16 decimal digits of precision Chapter 3 — Arithmetic for Computers — 23 Floating-Point Example � Represent –0.75 � –0.75 = (–1)1 × 1.12 × 2–1 � S = 1 � Fraction = 1000…002 � Exponent = –1 + Bias � Single: –1 + 127 = 126 = 011111102 � Double: –1 + 1023 = 1022 = 011111111102 � Single: 1011111101000…00 � Double: 1011111111101000…00 Chapter 3 — Arithmetic for Computers — 24 Floating-Point Example � What number is represented by the single- precision float 11000000101000…00 � S = 1 � Fraction = 01000…002 � Fxponent = 100000012 = 129 � x = (–1)1 × (1 + 012) × 2(129 – 127) = (–1) × 1.25 × 22 = –5.0 Chapter 3 — Arithmetic for Computers — 27 Floating-Point Addition � Consider a 4-digit decimal example � 9.999 × 101 + 1.610 × 10–1 � 1. Align decimal points � Shift number with smaller exponent � 9.999 × 101 + 0.016 × 101 � 2. Add significands � 9.999 × 101 + 0.016 × 101 = 10.015 × 101 � 3. Normalize result & check for over/underflow � 1.0015 × 102 � 4. Round and renormalize if necessary � 1.002 × 102 Chapter 3 — Arithmetic for Computers — 28 Floating-Point Addition � Now consider a 4-digit binary example � 1.0002 × 2–1 + –1.1102 × 2–2 (0.5 + –0.4375) � 1. Align binary points � Shift number with smaller exponent � 1.0002 × 2–1 + –0.1112 × 2–1 � 2. Add significands � 1.0002 × 2–1 + –0.1112 × 2–1 = 0.0012 × 2–1 � 3. Normalize result & check for over/underflow � 1.0002 × 2–4, with no over/underflow � 4. Round and renormalize if necessary � 1.0002 × 2–4 (no change) = 0.0625 Chapter 3 — Arithmetic for Computers — 29 FP Adder Hardware � Much more complex than integer adder � Doing it in one clock cycle would take too long � Much longer than integer operations � Slower clock would penalize all instructions � FP adder usually takes several cycles � Can be pipelined Chapter 3 — Arithmetic for Computers — 30 FP Adder Hardware Step 1 Step 2 Step 3 Step 4 Chapter 3 — Arithmetic for Computers — 33 FP Arithmetic Hardware � FP multiplier is of similar complexity to FP adder � But uses a multiplier for significands instead of an adder � FP arithmetic hardware usually does � Addition, subtraction, multiplication, division, reciprocal, square-root � FP ↔ integer conversion � Operations usually takes several cycles � Can be pipelined Chapter 3 — Arithmetic for Computers — 34 FP Instructions in MIPS � FP hardware is coprocessor 1 � Adjunct processor that extends the ISA � Separate FP registers � 32 single-precision: $f0, $f1, … $f31 � Paired for double-precision: $f0/$f1, $f2/$f3, … � Release 2 of MIPs ISA supports 32 × 64-bit FP reg’s � FP instructions operate only on FP registers � Programs generally don’t do integer ops on FP data, or vice versa � More registers with minimal code-size impact � FP load and store instructions � lwc1, ldc1, swc1, sdc1 � e.g., ldc1 $f8, 32($sp) Chapter 3 — Arithmetic for Computers — 35 FP Instructions in MIPS � Single-precision arithmetic � add.s, sub.s, mul.s, div.s � e.g., add.s $f0, $f1, $f6 � Double-precision arithmetic � add.d, sub.d, mul.d, div.d � e.g., mul.d $f4, $f4, $f6 � Single- and double-precision comparison � c.xx.s, c.xx.d (xx is eq, lt, le, …) � Sets or clears FP condition-code bit � e.g. c.lt.s $f3, $f4 � Branch on FP condition code true or false � bc1t, bc1f � e.g., bc1t TargetLabel Chapter 3 — Arithmetic for Computers — 36 FP Example: °F to °C � C code: float f2c (float fahr) { return ((5.0/9.0)*(fahr - 32.0)); } � fahr in $f12, result in $f0, literals in global memory space � Compiled MIPS code: f2c: lwc1 $f16, const5($gp) lwc2 $f18, const9($gp) div.s $f16, $f16, $f18 lwc1 $f18, const32($gp) sub.s $f18, $f12, $f18 mul.s $f0, $f16, $f18 jr $ra Chapter 3 — Arithmetic for Computers — 41 Interpretation of Data � Bits have no inherent meaning � Interpretation depends on the instructions applied � Computer representations of numbers � Finite range and precision � Need to account for this in programs The BIG Picture Chapter 3 — Arithmetic for Computers — 42 Associativity � Parallel programs may interleave operations in unexpected orders � Assumptions of associativity may fail §3.6 Parallelism and Computer Arithmetic: Associativity (x+y)+z x+(y+z) x -1.50E+38 -1.50E+38 y 1.50E+38 z 1.0 1.0 1.00E+00 0.00E+00 0.00E+00 1.50E+38 � Need to validate parallel programs under varying degrees of parallelism Chapter 3 — Arithmetic for Computers — 43 x86 FP Architecture � Originally based on 8087 FP coprocessor � 8 × 80-bit extended-precision registers � Used as a push-down stack � Registers indexed from TOS: ST(0), ST(1), … � FP values are 32-bit or 64 in memory � Converted on load/store of memory operand � Integer operands can also be converted on load/store � Very difficult to generate and optimize code � Result: poor FP performance §3.7 Real Stuff: Floating Point in the x86 Chapter 3 — Arithmetic for Computers — 44 x86 FP Instructions � Optional variations � I: integer operand � P: pop operand from stack � R: reverse operand order � But not all combinations allowed Data transfer Arithmetic Compare Transcendental FILD mem/ST(i) FISTP mem/ST(i) FLDPI FLD1 FLDZ FIADDP mem/ST(i) FISUBRP mem/ST(i) FIMULP mem/ST(i) FIDIVRP mem/ST(i) FSQRT FABS FRNDINT FICOMP FIUCOMP FSTSW AX/mem FPATAN F2XMI FCOS FPTAN FPREM FPSIN FYL2X Chapter 3 — Arithmetic for Computers — 48 Concluding Remarks � ISAs support arithmetic � Signed and unsigned integers � Floating-point approximation to reals � Bounded range and precision � Operations can overflow and underflow � MIPS ISA � Core instructions: 54 most frequently used � 100% of SPECINT, 97% of SPECFP � Other instructions: less frequent §3.9 Concluding Remarks
